STEEL APPLICATIONS
C-CLAW S1000
C-CLAW S1000 is a heavy-duty, adhesively bonded fastener for steel. It is engineered for demanding environments and applications on steel.
Ultimate capacity
Regulatory capacity
Diameter
Installation time
....................................... 90 kN (9000Kg)
.................................... 10kN (1000Kg)
.................................................................. 120 mm
....................................................< 20 min
C-CLAW S300
C-CLAW S300 is a non-intrusive fastener for steel that can be installed in less than two minutes by a single technician. It offers a fast, reliable, and durable alternative to welding or drilling.
Ultimate capacity
Regulatory capacity
Diameter
Installation time
..................................... 25kN (2500 Kg)
.................................... 3kN (300 Kg)
..................................................................70 mm
....................................................< 2 min
CONCRETE APPLICATIONS
C-BLOCK C500
C-BLOCK is a non-intrusive alternative to drilling and the use of anchors for concrete structures, particularly in nuclear power plants.
Co-developed with EDF for civil engineering and construction, this solution incorporates an intermediate layer that provides anti-seismic properties.
Ultimate capacity
Regulatory capacity
Diameter
Installation time
...................................... 12kN (1200Kg)
..................................... 5kN (500Kg)
................................................................... 111 m.........................................................< 1 h
C-BLOCK C100
C-BLOCK C100 is an industrial bonded fastener for concrete applications.
Its installation process, based on an advanced bonding system, eliminates the typical constraints of concrete drilling in construction and civil engineering projects.
.......................................... 6kN (600Kg)
...................................... 1kN (100Kg)
.................................................................. 70 mm....................................................... < 30 s
Ultimate capacity
Regulatory capacity
Diameter
Installation time
INSTALLATION TOOLS
C-HAWK L
The C-HAWK is a proprietary tool designed by Cold Pad for the installation of our bonded fasteners. It creates the perfect bonding environment by simulating laboratory conditions, providing the ideal level of humidity to ensure a successful bond in any environment. This tool provides complete data during the bonding process, such as humidity and pressure levels. It can be used to install our entire range of bonded fasteners.
C-HAWK S
C-HAWK S is Cold Pad's next-generation installation tool, designed to install C-CLAW S300 and C-BLOCK C100.
It creates the perfect bonding environment by simulating laboratory conditions, providing the ideal level of humidity to ensure a successful bond in any type of environment.
This tool is also light, user-friendly and compact, allowing for easy handling with minimal training.
